NGINX Load Balancing: Complete Guide to Algorithms & Setup

NGINX load balancing distributes incoming traffic across multiple backend servers to improve performance, reliability, and scalability. This comprehensive guide covers everything from basic round-robin to advanced algorithms like consistent hashing and the Power of Two Choices.

Unlike many tutorials that blindly copy-paste configurations, we’ll examine what actually happens under the hood by looking at NGINX source code. Understanding the internals helps you make informed decisions about which load balancing method fits your workload.

What is Load Balancing in NGINX?

Load balancing is the process of distributing network traffic across multiple servers. When you configure NGINX load balancing, it acts as a reverse proxy, accepting client requests and forwarding them to backend servers based on a configured algorithm.

The benefits include:

• High availability – If one server fails, traffic routes to healthy servers
• Horizontal scalability – Add more servers to handle increased load
• Better resource utilization – Spread work evenly across infrastructure
• Reduced latency – Route users to the fastest available server
• Zero-downtime deployments – Remove servers from rotation during updates

NGINX handles load balancing through the upstream block directive. Here’s a minimal example:

upstream backend {
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

server {
    listen 80;
    location / {
        proxy_pass http://backend;
    }
}

This configuration distributes requests across three backend servers using the default round-robin algorithm.

Installing NGINX with Load Balancing Support

On Rocky Linux, AlmaLinux, or other RHEL-compatible distributions, install NGINX from EPEL:

dnf install -y epel-release
dnf install -y nginx

Verify the installation and check available modules:

nginx -V

The standard NGINX package includes all load balancing modules. No additional compilation is required.

NGINX Load Balancing Algorithms

NGINX provides six algorithms for distributing traffic. Each has specific use cases and trade-offs. Choosing the right one depends on your application’s characteristics.

Round-Robin (Default)

When no algorithm is specified, NGINX uses weighted round-robin. Requests cycle through servers in order, with each server receiving traffic proportional to its weight.

upstream backend {
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX maintains three weight values for each server: weight, effective_weight, and current_weight. The algorithm selects the server with the highest current_weight, then reduces that weight by the total weight of all servers. This ensures perfect distribution over time.

When to use round-robin:

• Stateless applications where any server can handle any request
• Homogeneous server environments with similar capacity
• Simple deployments without complex session requirements

Weighted Round-Robin

Assign different weights to servers based on their capacity. A server with weight=5 receives five times more traffic than a server with weight=1.

upstream backend {
    server 192.168.1.10:8080 weight=5;  # 50% of traffic
    server 192.168.1.11:8080 weight=3;  # 30% of traffic
    server 192.168.1.12:8080 weight=2;  # 20% of traffic
}

Calculating weights: Base weights on actual server capacity. If server A has 16 CPU cores and server B has 8 cores, assign weight=2 and weight=1 respectively.

When to use weighted round-robin:

• Mixed hardware environments with different server capacities
• Gradual traffic shifting during migrations
• Canary deployments where new versions receive limited traffic

Least Connections

The least_conn directive routes each request to the server with the fewest active connections. This method works well when request processing times vary significantly.

upstream backend {
    least_conn;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX tracks active connections per server in the conns field. The selection formula accounts for weights: peer->conns * best->weight < best->conns * peer->weight. When multiple servers have equal weighted connections, round-robin breaks the tie.

Combining with weights:

upstream backend {
    least_conn;
    server 192.168.1.10:8080 weight=5;
    server 192.168.1.11:8080 weight=3;
    server 192.168.1.12:8080 weight=2;
}

The weighted comparison ensures higher-capacity servers accept proportionally more connections.

When to use least connections:

• Long-lived connections like WebSockets
• Requests with highly variable processing times
• API endpoints where some calls take much longer than others

IP Hash

The ip_hash directive ensures requests from the same client IP always go to the same server, providing session persistence without application-level session storage.

upstream backend {
    ip_hash;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX computes a hash using the formula hash = (hash * 113 + addr[i]) % 6271 with an initial hash value of 89. For IPv4, only the first three octets are used (the /24 subnet), so clients from the same subnet route to the same server. For IPv6, all 16 bytes are hashed.

Important limitation: If a server goes down, clients previously routed to it get redistributed. When the server returns, those clients switch back, potentially disrupting active sessions.

When to use IP hash:

• Applications with server-side session storage
• Legacy systems that cannot share sessions across servers
• Scenarios where sticky sessions are required but cookies aren’t viable

Generic Hash

The hash directive computes a hash from a configurable key. This provides more flexibility than IP hash.

upstream backend {
    hash $request_uri;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

You can hash any combination of NGINX variables:

upstream backend {
    hash $scheme$host$request_uri;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX uses CRC32 for hashing, with the expression ((crc32([REHASH] KEY) >> 16) & 0x7fff) + PREV_HASH. This is compatible with Cache::Memcached, making it useful for distributed caching scenarios.

When to use generic hash:

• Content-based routing (same URL always hits same cache server)
• User-based routing with custom session identifiers
• Distributed caching where cache locality matters

Consistent Hashing

Add the consistent parameter to enable consistent hashing, which minimizes redistribution when servers are added or removed from your upstream pool.

upstream backend {
    hash $request_uri consistent;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX creates 160 virtual nodes per weight unit for each server. These nodes are distributed around a hash ring. When a request arrives, NGINX hashes the key and finds the nearest virtual node using binary search.

Impact of server changes: With standard hashing, adding or removing a server redistributes most keys. With consistent hashing, only keys that would map to the changed server are affected, typically 1/n of total keys where n is the number of servers.

When to use consistent hashing:

• Distributed caching where cache invalidation is expensive
• Stateful services where session migration has high overhead
• Any scenario where minimizing redistribution during scaling matters

Random

The random directive selects a server randomly, weighted by server weights.

upstream backend {
    random;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX uses ngx_random() % total_weight to select a server. A binary search finds which server’s weight range contains the random value.

Random with Power of Two Choices

The random two least_conn configuration implements the “Power of Two Choices” algorithm, which provides near-optimal load distribution with minimal overhead.

upstream backend {
    random two least_conn;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

How it works internally: NGINX randomly selects two candidate servers, then picks the one with fewer active connections (weighted by server weights). This simple strategy dramatically reduces load imbalance compared to pure random selection.

When to use Power of Two Choices:

• Large server pools where tracking all connections is expensive
• Environments where servers have varying capacities
• As a simpler alternative to least connections with similar results

Server Parameters

Each server in an upstream block accepts parameters that control its behavior.

weight

Specifies the relative capacity of a server. Default is 1.

server 192.168.1.10:8080 weight=5;

max_conns

Limits the maximum number of simultaneous connections to a server. When the limit is reached, requests queue or fail over to other servers.

server 192.168.1.10:8080 max_conns=100;

This prevents overwhelming a server during traffic spikes. Set based on your server’s capacity and application requirements.

max_fails and fail_timeout

These parameters control passive health checking.

server 192.168.1.10:8080 max_fails=3 fail_timeout=30s;

• max_fails – Number of failed attempts before marking server unavailable (default: 1)
• fail_timeout – Time period for counting failures and duration of unavailability (default: 10s)

When a server fails max_fails times within fail_timeout, NGINX marks it unavailable for the remaining fail_timeout period. After that, NGINX tries again.

backup

Designates a server as backup. NGINX only uses backup servers when all primary servers are unavailable.

upstream backend {
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080 backup;
}

down

Permanently marks a server as unavailable. Use this for maintenance.

server 192.168.1.10:8080 down;

Connection Keepalive Optimization

By default, NGINX opens a new connection to the backend for each client request. For high-traffic sites, this creates significant overhead. Connection keepalive maintains persistent connections to backends.

upstream backend {
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
    keepalive 32;
}

Critical configuration for HTTP/1.1 backends:

location /api/ {
    proxy_pass http://backend;
    proxy_http_version 1.1;
    proxy_set_header Connection "";
}

Without proxy_http_version 1.1 and clearing the Connection header, keepalive won’t work. NGINX defaults to HTTP/1.0 for upstream connections, which closes connections after each response.

Additional keepalive parameters:

upstream backend {
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    keepalive 32;
    keepalive_requests 1000;
    keepalive_timeout 60s;
}

• keepalive 32 – Maximum idle connections per worker process
• keepalive_requests 1000 – Maximum requests per connection before closing
• keepalive_timeout 60s – Idle timeout for keepalive connections

For more performance tuning, see our guide on tuning worker_rlimit_nofile in NGINX and worker_processes.

Health Checks and Failover

NGINX provides multiple mechanisms for handling server failures.

Passive Health Checks

Configure with max_fails and fail_timeout:

upstream backend {
    server 192.168.1.10:8080 max_fails=3 fail_timeout=30s;
    server 192.168.1.11:8080 max_fails=3 fail_timeout=30s;
    server 192.168.1.12:8080 max_fails=3 fail_timeout=30s;
}

Request Failover

The proxy_next_upstream directive controls when NGINX retries a request on another server:

location /api/ {
    proxy_pass http://backend;
    proxy_next_upstream error timeout http_500 http_502 http_503 http_504;
    proxy_next_upstream_tries 3;
    proxy_next_upstream_timeout 10s;
}

• proxy_next_upstream – Conditions that trigger failover
• proxy_next_upstream_tries – Maximum retry attempts
• proxy_next_upstream_timeout – Total time limit for retries

Available conditions:

• error – Connection error or no response
• timeout – Connection timeout or response timeout
• invalid_header – Invalid response from server
• http_500, http_502, http_503, http_504 – Specific HTTP errors
• http_403, http_404, http_429 – Additional HTTP error codes
• non_idempotent – Allow retrying POST/PATCH/DELETE (disabled by default)
• off – Disable failover entirely

Connection Timeouts

Configure appropriate timeouts for your application:

location /api/ {
    proxy_pass http://backend;
    proxy_connect_timeout 10s;
    proxy_send_timeout 60s;
    proxy_read_timeout 60s;
}

Shared Memory Zones

For NGINX Plus or when using certain third-party modules, shared memory zones enable runtime state sharing across worker processes:

upstream backend {
    zone backend_zone 64k;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

The zone directive allocates shared memory for:

• Connection counts accurate across all workers
• Health check state
• Runtime configuration changes (NGINX Plus)

The size (64k in this example) should accommodate your server count. Each server entry requires approximately 1KB.

Advanced Modules for Load Balancing

The standard NGINX package covers most use cases, but third-party modules extend load balancing capabilities significantly. These modules are available as pre-built packages for RHEL-based distributions.

Sticky Cookie Session Persistence

The ip_hash directive has a major limitation: clients behind NAT or corporate proxies share the same IP address, causing uneven distribution. The sticky module solves this by using cookies for session persistence.

Install the module:

dnf install -y https://extras.getpagespeed.com/release-latest.rpm
dnf install -y nginx-module-sticky

Enable it in /etc/nginx/nginx.conf:

load_module modules/ngx_http_sticky_module.so;

Configure sticky sessions:

upstream backend {
    sticky name=route expires=1h domain=.example.com path=/ httponly secure;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

For enhanced security, use HMAC-signed cookies:

upstream backend {
    sticky hmac=sha1 hmac_key=your_secret_key name=route;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
}

When to use sticky cookies:

• Applications with server-side sessions behind load balancers
• Environments where clients share IP addresses (corporate networks, mobile carriers)
• When you need cryptographically secure session affinity

Fair Load Balancer

The fair module distributes requests based on backend response time, automatically sending more traffic to faster servers.

Install and enable:

dnf install -y nginx-module-upstream-fair

load_module modules/ngx_http_upstream_fair_module.so;

Configure fair balancing:

upstream backend {
    fair;
    server 192.168.1.10:8080;
    server 192.168.1.11:8080;
    server 192.168.1.12:8080;
}

When to use fair balancing:

• Heterogeneous backend environments with varying performance
• Applications where backend response times fluctuate
• When you want automatic adaptation to server load

Dynamic DNS Resolution

Standard NGINX resolves upstream hostnames only at startup or reload. The jdomain module enables dynamic DNS resolution, essential for cloud environments where backend IPs change frequently.

Install and enable:

dnf install -y nginx-module-upstream-jdomain

load_module modules/ngx_http_upstream_jdomain_module.so;

Configure dynamic resolution:

resolver 8.8.8.8;

upstream backend {
    jdomain api.example.com port=8080 max_ips=10 interval=10;
}

For auto-scaling environments with fallback:

upstream backend {
    server 127.0.0.2 backup;
    jdomain backend.internal.example.com port=8080 strict;
}

When to use dynamic DNS:

• Kubernetes or container orchestration platforms
• Auto-scaling groups in cloud environments
• Any scenario where backend IPs change without NGINX reload

Production Configuration Example

Here’s a complete production-ready NGINX load balancing configuration:

upstream backend_api {
    least_conn;
    zone backend_api 64k;

    server 192.168.1.10:8080 weight=5 max_fails=3 fail_timeout=30s max_conns=100;
    server 192.168.1.11:8080 weight=3 max_fails=3 fail_timeout=30s max_conns=100;
    server 192.168.1.12:8080 weight=2 max_fails=3 fail_timeout=30s max_conns=100;
    server 192.168.1.13:8080 backup;

    keepalive 32;
    keepalive_requests 1000;
    keepalive_timeout 60s;
}

server {
    listen 80;
    server_name api.example.com;

    location / {
        proxy_pass http://backend_api;

        # HTTP/1.1 for keepalive
        proxy_http_version 1.1;
        proxy_set_header Connection "";

        # Proper headers
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Timeouts
        proxy_connect_timeout 10s;
        proxy_send_timeout 60s;
        proxy_read_timeout 60s;

        # Failover
        proxy_next_upstream error timeout http_500 http_502 http_503 http_504;
        proxy_next_upstream_tries 3;
        proxy_next_upstream_timeout 10s;

        # Buffering
        proxy_buffering on;
        proxy_buffer_size 4k;
        proxy_buffers 8 16k;
        proxy_busy_buffers_size 32k;
    }
}

For more on proxy buffer configuration, see tuning proxy_buffer_size in NGINX.

Test the configuration before applying:

nginx -t

Reload NGINX to apply changes:

systemctl reload nginx

TCP/UDP Load Balancing with Stream Module

NGINX can also load balance TCP and UDP traffic using the stream module:

stream {
    upstream mysql_backend {
        least_conn;
        server 192.168.1.10:3306 max_fails=3 fail_timeout=30s;
        server 192.168.1.11:3306 max_fails=3 fail_timeout=30s;
        server 192.168.1.12:3306 backup;
    }

    server {
        listen 3306;
        proxy_pass mysql_backend;
        proxy_connect_timeout 10s;
        proxy_timeout 300s;
    }
}

The stream block typically goes in /etc/nginx/nginx.conf or a file included from there.

Monitoring Load Balancer Performance

Monitor your load balancer using NGINX’s stub status module:

server {
    listen 127.0.0.1:8080;

    location /nginx_status {
        stub_status;
        allow 127.0.0.1;
        deny all;
    }
}

Access the status page:

curl http://127.0.0.1:8080/nginx_status

This shows active connections, requests per second, and connection states.

For detailed upstream metrics, consider NGINX Plus or compatible monitoring solutions that parse NGINX logs.

Troubleshooting Common Issues

All Servers Marked as Unavailable

If all upstream servers fail health checks, NGINX returns 502 Bad Gateway. Check:

1. Backend server accessibility from the NGINX host
2. Firewall rules allowing traffic on backend ports
3. Backend application health

Uneven Load Distribution

With round-robin, verify all servers are actually receiving traffic:

1. Check server weights
2. Ensure keepalive connections aren’t causing stickiness
3. Verify all servers pass health checks

Connection Timeouts

If clients see timeouts:

1. Check proxy_connect_timeout for connection establishment
2. Verify proxy_read_timeout is sufficient for your slowest endpoints
3. Monitor backend server response times

Session Persistence Issues

If users lose sessions when switching servers:

1. Use IP hash or consistent hash for session stickiness
2. Implement shared session storage (Redis, Memcached)
3. Consider JWT tokens for stateless authentication

Summary

NGINX load balancing provides flexible, high-performance traffic distribution. Choose your algorithm based on your application’s needs:

• Round-robin for stateless applications with similar server capacity
• Least connections for requests with variable processing times
• IP hash for simple session persistence
• Consistent hash when minimizing redistribution during scaling matters
• Random with Power of Two Choices for large server pools
• Sticky cookies for reliable session affinity behind NAT
• Fair balancing for heterogeneous backend environments

Always configure proper health checks, connection keepalive, and failover behavior for production deployments. Test your configuration thoroughly before applying changes to live systems.

For more information, explore the official NGINX load balancing documentation.
